- Size: Frame width & profile thickness: 150mm/2.
- Place of Origin: GUANGDONG
- Brand Name: YALIAN
- Model Number: High Quality Aluminium Windows
- Weight: 1.000 kg
Specifications
1.simple, elegant with wide window and wide view
2.high reception of light
3.convenient to clean the glass.
4.resonable price
Introduction:
Tianyi window system features good sound insulation,better in energy-saving and comprehensive after-sale service.
A.Adopt 14.8mm or other type heat insulation strip.
B.Suitable for the area with high performance heat preservation, heat insulation .
C.Sash width ≥300mm;Sash height≤2400mm;Weight of window sash ≤250kg.
D.Side frame, follow the procedure of glue injection after corner crimping; Leading the flow of Sealant through sealant guide plate, increasing the intensity and Sealing performance of window corner.
E.Sash frame use plastic corner key connect through inside hexagonal bolt, easy connection, simples construction, less fabrication process, suitable for quantitive production and it’s very convenient to be changed for the dimension of sash and frame.
F.For more options from 16-22mm glazing.
G.Heat insulation can be achieved as 2.0W / m² k ~ 2.5W / m² k.
H.Beautiful shape, elevation effect concise and bright.
I.Use excellent hardware ,flexible opening, tiny opening and closing force, opening deft and agile, without noise.
J.Sealing design with anti-crash piece, Prevent shaking piece as an whole, convenient installation.
| Illustration to Thermal Break Aluminium Sliding Window | |
| Name of Product | Aluminum Sliding Window |
| Profile Series | Thermal Break |
| Profile Depth | 150mm |
| Profile Thickness | 2.0mm |
| Finishing | Powder coating, Electrophoresis, Anodize and PVDF |
| Color Option | Wide range and wood grain for options |
| Glass Option | tempered glass, Low-e glass,floated glass, refective glass,frosted glass,laminated glass and so on |
| Glass Thickness | 5mm+9A+5mm,6mm+12A+6mm double(triple)glazing |
| Sealant | EPDM, PVC,Silicone Sealant |
| Hardware | Chinese Kin Long, Greman Roto, Siegenia, Italian Guise, Belgium Sobinco, etc. |
| Dimension | Measurement(width*Height) supplied by the clients or standard size |
| Fly Screen | Available |
